10 Preface
The Example Application
This manual describes how to set up an example application. The
manual provides examples of each step of the setup, with references
to other manuals for more details.
System Components
We used the following devices and software for the example
application. For your own application, substitute your own devices to
fit your needs. The recommended configurations in this user manual
will help you set up the test system and get it working. Your eventual
configuration will depend on your application.
TIP
If you use different software or fimware versions of these
products, some of your dialogs may appear slightly different
from those shown in the example.
Quantity
Product Name
Catalog Number
Series/Revision
Hardware
1
SLC 500 modular chassis
1746-A4, 1746-A7, 1746-A10,
1746-A13
B
1
SLC 500 power supply
1746-P1, 1746-P2, 1746-P3,
1746-P4, 1746-P5, 1746-P6
-
1
SLC 5/04 processor
1747-L541, 1747-L542,
1747-L543
-
1
SLC 5/05 processor (Ethernet
network)
1747-L551, 1747-L552,
1747-L553
-
1
DeviceNet scanner module
1747-SDN/B
-
1
ControlNet RS-232 interface
module
1747-KFC15
B
1
DeviceNet quad-tap
1492-DN3TW
-
1
RediSTATION operator interface
module
2705-TxDN1x42x-xxxx
-
1
Series 9000 photoeye
42GNU-9000 or equivalent
-
1
DeviceNet RS-232 interface
module
1770-KFD
-
1
RS-232 cables
1787-RSCABL/A (personal
computer to 1770-KFD)
-
DeviceNet dropline or trunk
cables, as needed
1787-PCABL, 1787-TCABL,
1787-MCABL
-
