Page 45: Channel configuration, data, and status, Chapter

45
Publication 1746-UM614B-EN-P - September 2007
Chapter
6
Channel Configuration, Data, and Status
This chapter examines channel configuration and status words, and
explains how you use them. It gives you information about how to:
•
configure a channel.
•
check a channel’s status.
Channel Configuration
Channel configuration words appear in the SLC controller’s output
image table as shown below. Words 0…3 correspond to module
channels 0…3. Words 4…7 are not used.
After module installation, you must configure each channel to
establish the way the channel operates (for example, thermocouple
type and temperature units). You configure the channel by setting bits
in the configuration word using your programmer. We present bit
descriptions next.
For information on addressing, using your software and programming,
refer to Chapters 4, 5, and 7, respectively.
SLC Output Image (Configuration) Words
CH 0 Configuration Word
0
1
3
4
5
6
7
8
9
10
11
12
13
14
15
0
1
2
2
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0
1
3
4
5
6
7
8
9
10
11
12
13
14
15
0
1
3
4
5
6
7
8
9
10
11
12
13
14
15
CH 1 Configuration Word
CH 2 Configuration Word
CH 3 Configuration Word
•
•
O:e.0
O:e.1
O:e.2
O:e.3
O:e.4
O:e.7
Not Used
e = slot number of the module
