Chapter
3
Install and Wire the Module
This chapter tells you how to:
•
avoid electrostatic damage.
•
determine the module’s chassis power requirement.
•
install the module.
•
wire signal cables to the module’s terminal block.
•
install the ferrite collar.
Electrostatic Damage
Electrostatic discharge can damage semiconductor devices inside this
module if you touch backplane connector pins. Guard against
electrostatic damage by observing the following precautions.
•
Touch a grounded object to rid yourself of charge before
handling the module.
•
Wear an approved wrist strap when handling the module.
•
Handle the module from the front, away from the backplane
connector. Do not touch backplane connector pins.
•
Keep the module in its static-shield bag when not in use.
Power Requirements
The module receives its power through the SLC 500 chassis backplane
from the fixed or modular +5V dc/+24V dc chassis power supply. The
maximum current drawn by the module is shown in this table.
When using the module in a modular system, add the values shown
above to the requirements of all other modules in the SLC chassis to
prevent overloading the chassis power supply.
When using the module in a fixed controller, be sure not to exceed the
power supply rating for the pair of modules in the two slot I/O chassis.
ATTENTION
Electrostatic discharge can degrade performance or cause
permanent damage. Handle the module as stated below.
Maximum Current
5V dc
24V dc
0.11 A
0.085 A
