Appendix
A
Specifications
Table 12 - General Specifications - 1769-IT6
Attribute
1769-IT6
Dimensions (HxDxW), approx.
118 x 87 x 35 mm (4.65 x 3.43 x 1.38 in.)
height including mounting tabs is 138 mm (5.43 in.)
Shipping weight (with carton), approx.
276 g (0.61 lb)
Storage temperature
-40…85 °C (-40…185 °F)
Operating temperature
0…60 °C (32…140 °F)
Operating humidity
5…95% noncondensing
Operating altitude
2000 m (6561 ft)
Vibration, operating
10…500 Hz, 5 g, 0.030 in. peak-to-peak
Vibration, relay operation
2 g
Shock, operating
30 g, 11 ms panel mounted
(20 g, 11 ms DIN rail mounted)
Shock, relay operation
7.5 g panel mounted (5 g DIN rail mounted)
Shock, nonoperating
40 g panel mounted (30 g DIN rail mounted)
System power-supply distance rating
8 (The module may not be more than 7 modules away
from a system power supply.)
Recommended cable
Belden 8761 (shielded) for millivolt inputs
Shielded thermocouple extension wire for the specific
type of thermocouple you are using. Follow
thermocouple manufacturer’s recommendations.
Agency certification
C-UL certified (under CSA C22.2 No. 142)
UL 508 listed
CE compliant for all applicable directives
Hazardous environment class
Class I, Division 2, Hazardous Location, Groups A, B, C, D
(UL 1604, C-UL under CSA C22.2 No. 213)
Radiated and conducted emissions
EN50081-2 Class A
