Publication 1769-UM020A-EN-P - December 2009 51
Appendix
A
Specifications
Introduction
General Specifications –
1769-OF4
Topic Page
General Specifications – 1769-OF4 51
Output Specifications – 1769-OF4 52
Certifications – 1769-OF4 53
Replacement Parts 53
Attribute 1769-OF4
Dimensions (HxWxD), approx. 118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.)
Height including mounting tabs is 138 mm (5.43 in.)
Shipping weight
(with carton), approx. 280 g (0.61 lb)
Temperature, storage -40…85 °C (-40…185 °F)
Temperature, operating 0 …60 °C (32…140 °F)
Humidity, operating 5…95% noncondensing
Altitude, operating 2000 m (6561 ft)
Vibration, operating 10…500 Hz, 5 g, 0.030 in. peak-to-peak
Shock, operating 30 g, 11 ms panel mounted (20 g, 11 ms DIN rail
mounted)
Shock, nonoperating 40 g panel mounted (30 g DIN rail mounted)
Bus current draw, max 120 mA @ 5V DC; 170 mA @ 24V DC
Heat dissipation 2.86 Total Watts (The Watts per point plus the minimum
Watts with all points energized.)
Module OK indicator On: module has power, has passed internal diagnostics,
and is communicating over the bus
Off: Any of the above is not true
System power supply distance
rating The module may not be more than 8 modules away from
the system power supply
Cable, recommended Belden 8761 (shielded)
ESD immunity (IEC1000-4-2) 4 kV contact, 8 kV air, 4 kV indirect
Radiated immunity (IEC1000-4-3) 10V/m, 80…1000 MHz, 80% amplitude modulation
Fast transient burst (IEC1000-4-4) 2 kV, 5 kHz
Surge immunity (IEC1000-4-5) 1 kV galvanic gun
Conducted immunity (IEC1000-4-6) 10V, 0.15…80 MHz
