Publication 1769-UM020A-EN-P - December 2009 39
Module Data, Status, and Channel Configuration Chapter 3
This table describes how the ramp rate is determined for all output
types/ranges and output data formats.
If configured, ramping takes place only when the output is
commanded to go to a fault state. Ramping does not occur during
normal run operation.
Ramp Rates for Output Type/Range and Data Formats
Output Data Format Output Type/Range Total Counts in Full Scale Number of Counts for
Every 1% of Ramp Rate
Real Units/Second for
Every 1% of Ramp Rate
Proportional Counts
-10…10V DC
65,534
(1) 655
0.21V/s
0…5V DC 0.058V/s
0…10V DC 0.11V/s
1…5V DC 0.048V/s
0…20 mA 0.21 mA/s
4…20 mA 0.178 mA/s
Engineering Units
-10…10V DC 21,000 210 0.21V/s
0…5V DC 5750 58 0.058V/s
0…10V DC 11,000 110 0.11V/s
1…5V DC 4750 48 0.048V/s
0…20 mA 21,000 210 0.21 mA/s
4…20 mA 17,800 178 0.178 mA/s
Scaled for PID
-10…10V DC 17,203 172 0.21V/s
0…5V DC 18,840 188 0.058V/s
0…10V DC 18,021 180 0.11V/s
1…5V DC 19,455 195 0.048V/s
0…20 mA 17,202 172 0.21 mA/s
4…20 mA 18,226 182 0.178 mA
Percent of Full Scale
-10…10V DC 21,000 210 0.21V/s
0…5V DC 11,500 115 0.058V/s
0…10V DC 11,000 110 0.11V/s
1…5V DC 11,875 119 0.048V/s
0…20 mA 10,500 105 0.21 mA/s
4…20 mA 11,125 111 0.178 mA/s
(1) Limited to 32,767 by programming software.
