9-4 Sample Program
The information for the M1, M0, input image, output image, and the
rotator code is put into one data table. The layout of the file is as
follows:
Table 9.C BTM201.rss M1, M0, Input Image, Output Image, and Rotator Code Data Table
Location
Description
See Page
NXX
(1)
:0
Block header for the M1 configuration file
NXX:1 thru NXX:100
M1 configuration information
NXX:101 thru NXX:109
Reserved do not use
NA
NXX:110
Block header for the M0 file
NXX:111 thru NXX:159
M0 file information
NXX:160 thru NXX:175
Input image buffer
NXX:176 thru NXX:179
Reserved do not use
NA
NXX:180 thru NXX:195
Output image table
NXX:196 thru NXX:199
Reserved do not use
NA
NXX:200 thru NXX:203
Current set points
NA
NXX:204 thru NXX:207
Current error PV-SP
NA
NXX:208 thru NXX:211
Current CVs
NA
NXX:212 thru NXX:215
Error codes
NXX:216 thru NXX:219
CJC temperatures
NXX:220 thru NXX:223
Firmware revision
NXX:224 thru NXX:227
P contribution
NXX:228 thru NXX:231
I contribution
NXX:232 thru NXX:235
D contribution
NXX:236 thru NXX:239
Pre-set point
NA
NXX:240 thru NXX:243
Wait period
NA
NXX:244 thru NXX:247
Reserved for future use
NA
NXX:248 thru NXX:255
Reserved do not use
NA
(1)
The XX in all data table address above will depend on the data table location of the first BTM and which BTM is being
manipulated by the code.
