6-4 Rockwell Automation Publication 1492-UM008A-EN-P - June 2010
Chapter 6 First Time Use
Recommendations:
The ClearMark printer is now prepared for the first printing. Start up a new print
job with the ClearTools software.
Marker Type Catalog Numbers Color
Settings
600 dpi 1200 dpi
Snap-in individual markers:
1492-M, -MC, -MCS, -MN, -SM
White
H1 H1
1492-MCW H2 H2
Snap-in linked markers
1492-MR H2 H2
1492-MS H1 H1
Snap-in hinged markers 1492-MH H1 H1
Cable markers 1492-MW H1 H1
Self-adhesive cable markers 1492-MWL H1 H1
Wire markers 1492-MWC
All
Colors
H2 H2
Note: If Heating 1 causes bubbles on the surface, please change to Heating 2.
H1 = Heating 1, H2= Heating 2
ATTENTION: The required heat settings are dependent on
marker type, -color, -material and operating time of the
ClearMark printer. Please check the wipe and scratch resistance
in regular intervals.
ATTENTION: If a print job is unintentionally carried out without
heating it is possible to send an 'empty' print job to the printer
and set the correct heat settings H1/H2.
