Power supply – Rockwell Automation 1492-PRINT110_PRINT220 ClearMark Printer User Manual User Manual
Page 22

2-4
Rockwell Automation Publication 1492-UM008A-EN-P - June 2010
Chapter 2 Initial Set Up
Unplug the ClearMark Printer and contact a qualified service engineer if either of
the following occurs:
• The power cord is worn or damaged.
• The plug is worn or damaged.
Power supply
Connect the power cord to the ClearMark Printer and grounded outlet (220-240
VAC or 100-120 VAC). Make sure that the plug is completely inserted.
Top fuse:
• 10 A / delay-action 230V AC
• (12.5 A / delay-action 115V AC) → Power circuit of the fusing unit
Bottom fuse:
• 2 A / delay-action 230/115V AC → Printer controller
This device is subject to special conditions regarding its connection to the main
power supply (for European countries).
The supply impedance at the point of connection to the public electricity supply
must not exceed (0.14 +i 0.09) Ohm. If it does, consult the power supply
company before connecting the device to the public supply system.
ATTENTION: Do not carry out repairs to the device.
