Page | 38
Analog output parameters
Type of
output Voltage Current
Voltage Max. Range:
‐10.1 … +11 V DC
Min. Span: 2.5 V DC
Max. Range:
0 mA to 20 mA DC
Min. Span: 5 mA DC
Output – range
low Lowest Value
This is the minimum voltage value
at the output (related to 0% in‐
put).
Lowest Value
This is the minimum current value
at the output (related to 0% input).
Output – range
high Highest Value
This is the value at the output (re‐
lated to 100% input).
Highest Value
This is the maximum current value
at the output (related to 100% in‐
put).
Direct or
reverse function Direct action is output increasing
as input increases.
Reverse action is output decreas‐
ing as input increases. Direct action is output increasing
as input increases.
Reverse action is output decreas‐
ing as input increases.
Output – low limit Low Limit
This is the lowest possible value
at the output.
Low Limit
This is the lowest possible value at
the output.
Output – high lim‐
it High Limit
This is the highest possible value
at the output.
High Limit
This is the highest possible value at
the output.
Output – for error
condition Output @ Error
If an input or 931U‐C9C7C‐BC er‐
ror occurs the output is set to this
value.
Output @ Error
If an input or 931U‐C9C7C‐BC error
occurs the output is set to this val‐
ue.
