When auxiliary power is switched on,
for the first 200 ms the 931U‐C9C7C‐BC
will consume up to 200 mA.
5.3 Electrical Connections
Input, output and power supply wiring is made via
numbered, pluggable connectors, which may be
screw clamp or tension clamp type, depending on
the item article number.
The connectors are coded to prevent the power
supply connector being fitted in the wrong position.
Test terminals are included to permit input and
output currents to be monitored without discon‐
nection of cables (see connection diagram below).
WARNING!
931U‐C9C7C‐BC and PC have to be fully
de‐energized, before the programming
interfaces 931U‐CABLE will be connect‐
ed.
NOTICE
Ensure that the connectors are inserted
into the correct position (see connec-
tion diagram)
.
