Rockwell Automation 700-HX Multifunction Digital Timer User Manual
Page 44

Publication 700-UM002B-EN-D - June 2010
Appendix-3
Run Mode when Output Mode = Z
Function Setting Mode
Parameter
name
Parameter Setting range
Dafault
value
Unit
Set
value
Present
value,
cycle
time
Cycle
time
0.00
…
99.99
(Time range: --,--s)
0.00
s
0.0
…
999.9
(Time range: ---,-s)
0.0
s
0
…
9999
(Time range: ----s)
0
s
0
:
00
…
99
:
59
(Time range: --min--s)
0
:
00
min; s
0.0
…
999.9
(Time range: ---,-min)
0.0
min
0
…
9999
(Time range: ----min)
0
min
0
:
00
…
99
:
59
(Time range: --h--min)
0
:
00
h; min
0
.0
…
999.9
(Time range: ---,-h)
0.0
h
0
…
9999
(Time range:
----h)
0
h
0.000
…
9.999
(Time range: -,---s)
0.000
s
Present
value
Same as cycle time above
Same
as left
Same
as left
Present
value,
ON
duty
ratio
ON
duty
ratio
0
…
100
0
%
Present
value
Same as cycle time above
Same
as left
Same
as left
Parameter name
Parameter Setting range
Dafault
value
Unit
Set
value
Time range
timr
--,--s/---,-s/----s/--min--s/
---,-min/----min/--h--min/
---,-h/----h/-,---s
---
Timer mode
timm
up down
up
---
Output mode
outm
a a-1 a-2 a-3 b b-1
d e f s
a
---
Output time
otim
hold 0.01 to 99.99
hold
s
Input signal width
iflt
20ms 1ms
20ms
---
Key protect level
kypt
kp-1 kp-2 kp-3
kp-4 kp-5 kp-6
kp-7
kp-1
---
