Preface
Manual Objectives
The purpose of this manual is to provide you with the additional information
necessary to apply the 700-HX Multifunction Digital Timer. Described in this
manual are methods for applying and troubleshooting this product.
Who Should Use This
Manual
This manual is intended for qualified personnel responsible for setting up and
servicing these devices. You must have previous experience with and a basic
understanding of wiring diagrams, configuration procedures, related equipment,
and safety precautions.
Counter/Timer Mode
Explanation
In this manual we refer to the Timer Output Modes with the following
designations:
A: Signal ON delay 1
A-1: Signal ON delay 2
A-2: Power ON delay 1
A-3: Power ON delay 2
B: Repeat Cycle 1
B-1: Repeat Cycle 2
D: Signal OFF delay
E: One Shot
F: Cumulative
Z: ON/OFF-duty adjustable repeat cycle
S: Stop Watch
toff: Flicker OFF start 1(Timer resets when power comes on)
ton: Flicker ON start 1 (Timer resets when power comes on)
toff-1: Flicker OFF start 2(Timer does not reset when power comes on)
ton-1: Flicker ON start 2 (Timer does not reset when power comes on)
Note: In this manual the 700-HX Multifunction Digital Timer will be referred to
as “700-HX.” For further information, please refer to the Industrial Controls
Catalog or www.ab.com/catalogs.
