Frames 9…14 – Rockwell Automation 20D-P2-SLBO PowerFlex 700S Drive Phase II Control SynchLink Board User Manual
Page 5
Rockwell Automation Publication 20D-IN010B-EN-P - November 2010
5
SynchLink™ Board for PowerFlex® 700S Drives with Phase II Control
Frames 9…14
1. If necessary, disconnect any fiber-optic ControlNet and SynchLink cables
from the control assembly.
2. Disconnect any remaining I/O and communications cables from the
control assembly.
3. Disconnect the ribbon cables from the main control board.
4. Loosen the captive screw on the control assembly mounting plate and
swing the control assembly mounting plate away from the control frame.
ATTENTION: Hazard of permanent eye damage exists when using optical
transmission equipment. This product emits intense light and invisible
radiation. Do not look into fiber-optic ports or fiber-optic cable connectors.
X50
Frame 9
Frames 10…14
Loosen captive screw and swing
mounting plate away from drive.
=
