Troubleshooting 5-5
The following adapter diagnostic items can be viewed using
DriveExplorer (version 3.01 or higher) or DriveExecutive (version 3.01
or higher) software, or an LCD PowerFlex HIM (Diagnostic/Device
Items).
To view and clear adapter diagnostic items
Viewing and Clearing Adapter Diagnostic Items
Step Keys Example Screen
Viewing Diagnostic Items
1. Access parameters in the adapter.
Refer to Using the PowerFlex
7-Class HIM on page 3-2 .
2. Press the Up Arrow or Down Arrow
to scroll to Diagnostics.
3. Press Enter to display the
Diagnostics menu in the adapter.
4. Repeat steps 2 and 3 to enter the
Device Items option.
5. Press the Up Arrow or Down Arrow
to scroll through the items.
Clearing Diagnostic Items
1. Access parameters in the Adapter.
Refer to Using the PowerFlex
7-Class HIM on page 3-2 .
2. Press the Up Arrow or Down Arrow
to scroll to Parameter.
3. Press Enter to display the list of
parameters in the adapter.
4. Repeat steps 2 and 3 to select
Parameter 28 - [Clear Counters].
5. Set the value to 1 = Clear and then
press Enter to clear the following
diagnostic items: 24, 25, 26, 27, and
28.
OR
OR
OR
Main Menu:
Diagnostics
Parameter
Device Select
Device Item # 13
MAC Addr SW
1
Parameter #: 28
Clear Counters
1
Clear
Main Menu:
Diagnostics
Parameter
Device Select
