Getting Started 1-3
The 20-COMM-B BACnet MS/TP adapter is compatible with most
Allen-Bradley PowerFlex 7-Class (Architecture-Class) drives and other
products that support DPI. DPI is a second generation peripheral
communication interface and functional enhancement to SCANport. At
the time of publication, compatible products include:
Equipment Shipped with the Adapter
When you unpack the adapter, verify that the package includes:
User-Supplied Equipment
To install and configure the adapter, you must supply:
Compatible Products
• PowerFlex 70 drives (standard and enhanced control)
• PowerFlex 700 drives (standard and vector control)
• PowerFlex 700 Series B drives (standard and vector control)
• PowerFlex 700H drives
• DPI External Comms Kit
Required Equipment
❑ One 20-COMM-B BACnet MS/TP adapter
❑ A 2.54 cm (1 in.) and a 15.24 cm (6 in.) Internal Interface cable
(only one cable is needed to connect the adapter to the drive)
❑ One 3-pin linear plug (plugged into the adapter socket)
❑ This manual
❑ A small flathead screwdriver
❑ A shielded, twisted wire pair to connect the adapter to the network
❑ A configuration tool, such as:
– PowerFlex HIM
– DriveExplorer (version 3.01 or higher)
– DriveExecutive stand-alone software (version 3.01 or higher) or
bundled with the DriveTools SP suite (version 1.01 or higher)
– Third-party network configuration software
