PowerFlex 400 Adjustable Frequency AC Drive Quick Start
English-5
Specifications, Fuses and Circuit Breakers
Drive Ratings
Catalog
Number
Output Ratings Input Ratings
Branch Circuit Protection
Power
Dissipation
kW (HP)
Amps
Voltage
Range
kVA Amps
Fuses
(1)
140M Motor
Protectors
(2)
(3)
Contactors
Min.
Enclosure
Volume
(4)
(in.
3
)
IP20 Open
Watts
50°C
200 - 240V AC – 3-Phase Input, 0 - 230V 3-Phase Output
22C-B012N103 2.2 (3.0)
12
180-265 6.5
15.5
20
140M-F8E-C16 100-C23
5098
146
22C-B017N103 3.7 (5.0)
17.5
180-265 8.8
21
30
140M-F8E-C25 100-C37
5098
207
22C-B024N103 5.5 (7.5)
24
180-265 10.9 26.1
35
140M-F8E-C32 100-C37
5098
266
22C-B033N103 7.5 (10)
33
180-265 14.4 34.6
45
140M-F8E-C45 100-C45
5098
359
22C-B049A103 11 (15)
49
180-265 21.3 51
70
–
100-C60
–
488
22C-B065A103 15 (20)
65
180-265 28.3 68
90
–
100-C85
–
650
22C-B075A103 18.5 (25) 75
180-265 32.5 78
100
–
100-D95
–
734
22C-B090A103 22 (30)
81
180-265 38.3 92
125
–
100-D110
–
778
22C-B120A103 30 (40)
120
180-265 51.6 124
175
–
100-D180
–
1055
22C-B145A103 37 (50)
130
180-265 62.4 150
200
–
100-D180
–
1200
380 - 480V AC – 3-Phase
Input, 0 - 460V 3-Phase Output
22C-D6P0N103 2.2 (3.0)
6
340-528 6.3
7.5
10
140M-D8E-C10 100-C09
5098
105
22C-D010N103 4.0 (5.0)
10.5
340-528 10.9 13
20
140M-D8E-C16 100-C16
5098
171
22C-D012N103 5.5 (7.5)
12
340-528 11.9 14.2
20
140M-D8E-C16 100-C23
5098
200
22C-D017N103 7.5 (10)
17
340-528 15.3 18.4
25
140M-D8E-C20 100-C23
5098
267
22C-D022N103 11 (15)
22
340-528 19.2 23
30
140M-F8E-C32 100-C30
5098
329
22C-D030N103 15 (20)
27
340-528 25.8 31
40
140M-F8E-C32 100-C37
5098
435
22C-D038A103 18.5 (25) 38
340-528 33.3 40
50
140M-F8E-C45 100-C60
9086
606
22C-D045A103 22 (30)
45.5
340-528 39.1 47
60
–
100-C60
–
738
22C-D060A103 30 (40)
54
340-528 53.3 64
80
–
100-C85
–
664
22C-D072A103 37 (50)
72
340-528 60.7 73
100
–
100-C85
–
1019
22C-D088A103 45 (60)
88
340-528 74.9 90
125
–
100-D110
–
1245
22C-D105A103 55 (75)
105
340-528 89
107
150
–
100-D140
–
1487
22C-D142A103 75 (100)
128
340-528 124.8 150
200
–
100-D180
–
2043
22C-D170A103 90 (125)
170
340-528 142
170
250
–
100-D250
–
2617
22C-D208A103 110 (150) 208
340-528 167
200
250
–
100-D250
–
3601
(1)
Recommended Fuse Type: UL Class J, CC, T or Type BS88; 600V (550V) or equivalent.
(2)
The AIC ratings of the Bulletin 140M Motor Protector Circuit Breakers may vary. See
.
(3)
Manual Self-Protected (Type E) Combination Motor Controller, UL listed for 208 Wye or Delta, 240
Wye or Delta, 480Y/277 or 600Y/347. Not UL listed for use on 480V or 600V Delta/Delta, corner
ground, or high-resistance ground systems.
(4)
When using a Manual Self-Protected (Type E) Combination Motor Controller, the drive must be
installed in a ventilated or non-ventilated enclosure with the minimum volume specified in this
column. Application specific thermal considerations may require a larger enclosure.
