PowerFlex 400 Adjustable Frequency AC Drive Quick Start English-21
T082
T085 [Analog Out1 Sel]
[Analog Out2 Sel] 0/20 1 0
1
T083
T086 [Analog Out1 High]
[Analog Out2 High] 0/800% 1% 100%
T084
T087 [Anlg Out1 Setpt]
[Anlg Out2 Setpt] 0.0/100.0% 0.1% 0.0%
T088 [Anlg Loss Delay] 0.0/20.0 Secs 0.1 Secs 0.0 Secs
No. Parameter Min/Max Display/Options Default
Setting
Output
Range Min. Output
Value
Max. Output Value Filter
DIP Switch
AO1 Related
Parameter
0 OutFreq 0-10 0-10V 0V = 0 Hz [Maximum Frequency] None 10V b001
1 OutCurr 0-10 0-10V 0V = 0 Amps 200% Drive Rated FLA Filter A 10V b003
2 OutTorq 0-10 0-10V 0V = 0 Amps 200% Drive Rated FLA Filter A 10V b013
3 OutVolt 0-10 0-10V 0V = 0 Volts 120% Drive Rated Output V None 10V b004
4 OutPowr 0-10 0-10V 0V = 0 kW 200% Drive Rated Power Filter A 10V b010
5 Setpnt 0-10 0-10V 0V = 0.0% 100.0% Setting None 10V T084
6 TstData 0-10 0-10V 0V = 0000 65535 (Hex FFFF) None 10V A196
7 OutFreq 0-20 0-20 mA 0 mA = 0 Hz [Maximum Frequency] None 20 mA b001
8 OutCurr 0-20 0-20 mA 0 mA = 0 Amps 200% Drive Rated FLA Filter A 20 mA b003
9 OutTorq 0-20 0-20 mA 0 mA = 0 Amps 200% Drive Rated FLA Filter A 20 mA b013
10 OutVolt 0-20 0-20 mA 0 mA = 0 Volts 120% Drive Rated Output V None 20 mA b004
11 OutPowr 0-20 0-20 mA 0 mA = 0 kW 200% Drive Rated Power Filter A 20 mA b010
12 Setpnt 0-20 0-20 mA 0 mA = 0.0% 100.0% Setting None 20 mA T084
13 TstData 0-20 0-20 mA 0 mA = 0000 65535 (Hex FFFF) None 20 mA A196
14 OutFreq 4-20 4-20 mA 4 mA = 0 Hz [Maximum Frequency] None 20 mA b001
15 OutCurr 4-20 4-20 mA 4 mA = 0 Amps 200% Drive Rated FLA Filter A 20 mA b003
16 OutTorq 4-20 4-20 mA 4 mA = 0 Amps 200% Drive Rated FLA Filter A 20 mA b013
17 OutVolt 4-20 4-20 mA 4 mA = 0 Volts 120% Drive Rated Output V None 20 mA b004
18 OutPowr 4-20 4-20 mA 4 mA = 0 kW 200% Drive Rated Power Filter A 20 mA b010
19 Setpnt 4-20 4-20 mA 4 mA = 0.0% 100.0% Setting None 20 mA T084
20 TstData 4-20 4-20 mA 4 mA = 0000 65535 (Hex FFFF) None 20 mA A196
T083 Setting T082 Setting T082 Max. Output Value
50% 1 “OutCurr 0-10” 5V for 200% Drive Rated Output Current
90% 11 “OutPowr 0-20” 18 mA for 200% Drive Rated Power
Communications Group Parameters
No. Parameter Min/Max Display/Options Default
C101 [Language] 1/10 1 = “English”
2 = “Français”
3 = “Español”
4 = “Italiano”
5 = “Deutsch” 6 = “Reserved”
7 = “Português”
8 = “Reserved”
9 = “Reserved”
10 = “Nederlands” 1
C102 [Comm Format] 0/9 0 = “RTU 8-N-1”
1 = “RTU 8-E-1”
2 = “RTU 8-O-1”
3 = “RTU 8-N-2”
4 = “RTU 8-E-2” 5 = “RTU 8-O-2”
6 = “MetaSys N2”
7 = “P1 8-N-1”
8 = “P1 8-E-1”
9 = “P1 8-O-1” 0
Power to drive must be cycled before any
changes will affect drive operation.
C103 [Comm Data Rate] 0/5 0 = “1200”
1 = “2400”
2 = “4800” 3 = “9600”
4 = “19.2K”
5 = “38.4K” 0
C104 [Comm Node Addr] 1/247 1 100
C105 [Comm Loss Action] 0/5 0 = “Fault”
1 = “Coast Stop”
2 = “Stop” 3 = “Continu Last”
4 = “Run Preset 0”
5 = “Kypd Inc/Dec” 0
C106 [Comm Loss Time] 0.1/60.0 Secs 0.1 Secs 5.0 Secs
C107 [Comm Write Mode] 0/1 0 = “Save” 1 = “RAM Only” 0
C108 [Start Source 2] 0/6 0 = “Keypad”
1 = “3-Wire”
2 = “2-Wire” 3 = “2-W Lvl Sens”
4 = “2-W Hi Speed”
5 = “Comm Port”
6 = “2-W Lvl/Enbl” 3
Sets the control scheme used to start the drive
when in Auto/Remote mode.
C109 [Speed Ref 2] 0/5 0 = “Drive Keypad”
1 = “InternalFreq”
2 = “Analog In 1” 3 = “Analog In 2”
4 = “Preset Freq”
5 = “Comm Port” 2
