Frame Parts
10.8 2014 (U1 REVISED) Comp 10
Head Jambs
A
B=
Sidelite
(Active)
A
Code F
2.520”
1.359” C = Door
(Active)
A
B
R .250 (2)
Code F
2.520”
1.359” C B
R 0.250” (2)
Flush with
Door Rabbet
A B C
24UL2 / 24UR2 = 2/4 L(R) W/1-12" VENTING SL 41.721 11.677
24UL4 / 24UR4 = 2/4 L(R) W/1-14" VENTING SL 43.721 13.677
26UL2 / 26UR2 = 2/6 L(R) W/1-12" VENTING SL 43.721 11.677
26UL4 / 26UR4 = 2/6 L(R) W/1-14" VENTING SL 45.721 13.677
28UL2 / 28UR2 = 2/8 L(R) W/1-12" VENTING SL 45.721 11.677
28UL4 / 28UR4 = 2/8 L(R) W/1-14" VENTING SL 47.721 13.677
21UL2 / 21UR2 = 2/10 L(R) W/1-12" VENTING SL 47.721 11.677
21UL4 / 21UR4 = 2/10 L(R) W/1-14" VENTING SL 49.721 13.677
30UL2 / 30UR2 = 3/0 L(R) W/1-12" VENTING SL 49.721 11.677
30UL4 / 30UR4 = 3/0 L(R) W/1-14" VENTING SL 51.721 13.677
(MACHINING CODE F)
WIDE MULLION
CONTINUOUS WITH 1 VENTING SIDELITE
27.524
29.524
31.524
33.524
35.524
A B C
24U12 = 2/4 SINGLE W/2-12" VENTING SL 55.408 11.677
24U14 = 2/4 SINGLE W/2-14" VENTING SL 59.408 13.677
26U12 = 2/6 SINGLE W/2-12" VENTING SL 57.408 11.677
26U14 = 2/6 SINGLE W/2-14" VENTING SL 61.408 13.677
28U12 = 2/8 SINGLE W/2-12" VENTING SL 59.408 11.677
28U14 = 2/8 SINGLE W/2-14" VENTING SL 63.408 13.677
21U12 = 2/10 SINGLE W/2-12" VENTING SL 61.408 11.677
21U14 = 2/10 SINGLE W/2-14" VENTING SL 65.408 13.677
30U12 = 3/0 SINGLE W/2-12" VENTING SL 63.408 11.677
30U14 = 3/0 SINGLE W/2-14" VENTING SL 67.408 13.677
487U12 = 4/8 FRENCH W/2-12" VENTING SL 84.126 11.677
487U14 = 4/8 FRENCH W/2-14" VENTING SL 88.126 13.677
507U12 = 5/0 FRENCH W/2-12" VENTING SL 88.126 11.677
507U14 = 5/0 FRENCH W/2-14" VENTING SL 92.126 13.677
547U12 = 5/4 FRENCH W/2-12" VENTING SL 92.126 11.677
547U14 = 5/4 FRENCH W/2-14" VENTING SL 96.126 13.677
587U12 = 5/8 FRENCH W/2-12" VENTING SL 96.126 11.677
587U14 = 5/8 FRENCH W/2-14" VENTING SL 100.126 13.677
607U12 = 6/0 FRENCH W/2-12" VENTING SL 100.126 11.677
607U14 = 6/0 FRENCH W/2-14" VENTING SL 104.126 13.677
55.732
59.732
63.732
67.732
71.732
29.014
31.014
33.014
35.014
WIDE MULLION
(MACHINING CODE F)
27.014
SI
N
G
LE
CONTINUOUS WITH 2 VENTING SIDELITES
FR
EN
C
H
