Frame Parts
Comp 10 2014 (U1 REVISED) 10.13
Hinge 1
Hinge 2
Hinge 3
Hinge 4
8/0 Jamb Shown
R .625”
or
R.250”
4.015” .728”
Jamb
stop
.092”
Deep
UNIT HEIGHT UNIT WIDTH HINGE 1 HINGE 2 HINGE 3 HINGE 4
6/8 9.872 37.312 64.750 N/A
8/0 10.985 34.235 57.485 80.735
3/0 9.875 33.000 56.124
3/6 8.874 31.000 53.124
3/0 31.374 51.749 72.124
3/6 30.374 49.749 69.124
10.999
N/A
HINGE MORTISE LOCATIONS
A
RCH
SI
D
E
JA
MB
RA
DI
US
SI
D
E
JA
MB
8/0
6/8
3/0 OR 3/6
Side Jambs
