Frame Parts
10.28 2014 (U1 REVISED) Comp 10
Mull Casing
Wood Mull Casing
Length: Standard = 81-1/4”
Transom = 95-3/4”
8/0 Height = 98”
1-15/32”
1-1/16”
1-7/32”
1-1/16”
Mull Casing - Inswing Mull Casing - Outswing
Screen Track and Stop
1.068”
.625”
Screen Track
.411”
1.340”
Screen Track Base
Screen Stop
Cover
Triple Patio Screen Stop
"BASE"
LENGTH
"COVER"
LENGTH
6/6 77.141 77.906
6/8 79.485 80.250
8/0 95.485 96.250
SIZE
"A"
OVERALL
LENGTH
4/8 56.938
5/0 60.938
5/4 64.938
5/8 68.938
6/0 72.938
4/8 57.438
5/0 61.438
5/4 65.438
5/8 69.438
6/0 73.438
ST
A
N
D
A
R
D
M
U
LLI
O
N
WI
D
E M
U
LLI
O
N
UNDERSIZE
UNDERSIZE
