Frame Parts
10.18 2014 (U1 REVISED) Comp 10
Mullions
Standard Lock
Mortise location
Top of
Mullion
Lock
Center
Distance
.250 R
.114” 1.133”
2.236”
.728”
.094”
Deep
.250 R x .469”
Deep
Entry Mullion Shown
UNIT SIZE STRIKE
6/6
6/8
8/0
60.094
44.094
MACHINING CODE J
