Frame Parts
10.12 2014 (U1 REVISED) Comp 10
Side Jambs
Hinge 1
Hinge 2
Hinge 3
Hinge 4
8/0 Jamb Shown
R .625
or
R.250
4.015” .728”
Jamb
stop
.097”
Deep
.135”
Deep
R .625
3.654”
1.320”
R .250
4.106”
.804”
Jamb
stop
Adjustable Hinge
Standard Hinge
UNIT SIZE HINGE [1] HINGE [2] HINGE [3] HINGE [4]
6/6
6/8
8/0 34.125 59.625 84.625
6/6
6/8
8/0 6.306 31.806 57.306 82.806
HINGE MORTISE LOCATIONS
ST
AN
DA
RD
HI
NG
E
(M
AC
HIN
IN
G
CO
DE
S 4,
5)
UN
DE
RS
IZ
E
9.125
38.875 68.625 N/A
AD
JU
ST
AB
LE
HI
NG
E
(M
ACH
INI
NG
CO
DE
A)
UN
DE
RS
IZ
E
9.400 38.650 67.900 N/A
