Regency Horizon™ HZ42STE Gas Fireplace
43
INSTALLATION
24) Reconnect electrical supply - test lights.
25) Reverse steps 8 -2.
23) Attach ground wire to ground lug - and plug in light assembly.
Note: The receptacle can be mounted in 2 locations in the fi rebox.
(see below)
Receptacle
Ground Lug Ground Lug
Receptacle can also
be mounted on this side
Vent Side of Unit
Top View - fl oor of unit
4) Remove one screw securing the socket end of the diffuser and
separate the 2 parts - as shown below.
3) Pull out light diffuser.
BULB REPLACEMENT
1) Slide out bottom faceplate panel - see step 3 from previous page.
2) Remove 4 screws securing light diffuser mounting plate.
6) Reverse steps 3 through 1.
5) Replace bulb.
Note : Oils from hands will shorten the life of the bulbs,
do not handle bulbs with bare hands.
21) Repeat steps 12-20 to install the 3 remaining light diffusers .
22) After all light diffusers are installed - manage wiring so that it is
neatly arranged and out of the way - as shown below.
20) Secure socket to light diffuser with one screw - as shown below.
