Sunnex CS2050D-MRI (Dual Ceiling) - Manual (Page 6)

Sunnex Celestial Star MRI Service & Installation Manual
6
3. CELESTIAL STAR MRI SPECIFICATIONS
3.1 TECHNICAL DATA
Power supply:
120V - 60Hz and 230V - 50Hz
Nominal Effect: 120Vac, 60Hz, 50W - 1.7A
230Vac, 50Hz, 50W - 1.0A
Light Source: Halogen bulb - Dichroic 3 x 12V/35W/10°
Bulb Life: 4,000 hours
Central Illuminance: 40,000 Lux at 1m
Total Irradiance: 79.3 Watts/m
2
Color Temp: 3,153K
Color Rendering Index: 97
Total Weight: Mobile 40 lbs / 18 kg
Ceiling 52 lbs / 23kg
This product is rated as a Class II medical device, mode of operation is suited for continuous use. The
product is rated as class I according to electrical safety standards and conforms to CAN/CSA-C22.2 No.
601.1-M-90, EN 60601-1:1990, IEC 60601-2-41: 2000, UL 60601-1, First edition, 2003.
This product does not produce any physiological effects that could harm a patient. The mains plug on the
product is a disconnect device, a mains switch is not provided.
This product is not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen
or nitrous oxide.
The normal operating temperature for the product is -5°F / -20°C to 140°F / 60°C.
Technical Questions
Any technical questions can be directed to
America:
Sunnex Inc. phone +1 508 651 0009
Attn: Engineering Department
3 Huron Drive, Natick, MA 01760, USA.
Europe:
Sunnex Equipment AB +1 46 (0) 565 177 00
Attn: Engineering Department
Smidesvagen 7, PO Box 555, S-686 28, Sunne, Sweden
