Sunnex Celestial Star MRI Service & Installation Manual
18
4.2.3 ATTACH BALANCE ARM TO EXTENSION ARM
Follow these instructions to attach balance arm to the extension arm
1. Do not attach the counter weight to the balance arm prior to connecting the balance arm to the extension
arm.
2. Connect the male Molex connector with the female Molex connector and ensure that the positive latch on
the connectors is achieved. Refer to Figure 3. Position the connection in such a way that the wires will not
be compromised by securing the extension arm to the balance arm.
4. Line up the holes on the bottom of the extension arm with the holes on the arm joint at the balance arm.
5. Use the provided stainless steel thumb screws (3 X 8-32 X ½”) to secure the connection. If needed, use a
wrench to tighten the screws.
CAUTION! IF THE MAGNET IS ACTIVE, USE EXTREME CAUTION WHEN BRINGING
TOOLS INTO THE MRI ENVIRONMENT. NON MAGNETIC TOOLS SHOULD BE USED
TO THE EXTENT POSSIBLE. FAILURE TO FOLLOW MRI RULES AND GUIDELINES
MAY RESULT IN SERIOUS INJURY.
6. Once the light is securely in place, fix the round counter weight to other end of the lamp head balance
arm. There are two counter sunk holes on this end of balance arm. Position the counter weight on the
opposite side of the counter sunk holes on the balance arm. Set the two supplied Hex screws in the counter
sunk holes and tighten them down using provided Allen wrench.
CAUTION! THE PROVIDED ALLEN WRENCH CONTAINS FERROUS MATERIALS. IF
THE MAGNET IS ACTIVE, USE EXTREME CAUTION WHEN BRINGING TOOLS INTO
THE MRI ENVIRONMENT. NON MAGNETIC TOOLS SHOULD BE USED TO THE
EXTENT POSSIBLE. FAILURE TO FOLLOW MRI RULES AND GUIDELINES MAY
RESULT IN SERIOUS INJURY.
* Connect the sterilizable handle onto the screw at the center of the lamp head.
* Plug the hospital grade plug into the receptacle. Your light is ready for use.
4.2.4 ELECTRICAL CONNECTIONS
Option 1 – Installing the transformer box outside MRI room using RF filter
The transformer box is equipped with 30ft of cord on the secondary side and 10ft of cord on the primary
side. If installing the transformer box outside the MRI room, connectors may be required on the secondary
side to accommodate the use of an RF filter. RF filter connectors will be different based on which RF filter is
used. Total length of cord on the secondary side should not be altered from the original 30ft. If your facility
construction requires alterations beyond these guidelines, please contact Sunnex Technical Support.
WHICH RF FILTER TO USE
Celestial Star specifications:
Power Supply:
120V - 60Hz and 230V - 50Hz
Nominal Effect: 120VAC, 60Hz, 3x35W - 1.7A
230VAC, 50Hz, 3x35W - 1.0A
