Stainless Works Ford Crown Vic / Mercury Grand Marquis 2003-11 Headers - Manual

WWW.STAINLESSWORKS.NET 800-878-3635 FAX: 440-543-9183
INSTALLATION INSTRUCTIONS FOR 03-08 CROWN VICTORIA
HEADERS
Thanks for purchasing Stainless Works Muscleflow Headers for your 03-08 Crown
Victoria. We have gone to great pains to make sure that our exhaust systems fit and
sound great. Please follow these steps to ensure that your installation goes as planned.
1. Stainless Works recommends the use of Permatex Hi-Temp RTV silicon gasket
maker as an option to or in conjunction with the use of factory gaskets. The
recommended RTV is Sensor-Safe P/N 101BR or 27BR, available at NAPA and
other retailers.
2. Disconnect the battery before starting work on the exhaust system for your
vehicle. Reconnect the battery when the job is completed.
3. Your exhaust system can be installed by a weekend warrior but the use of a lift is
recommended for ease of installation. If using a jack, the vehicle must be placed
on a level hard surface and jack stands are required for safety reasons.
4. Raise and support the vehicle.
5. Mark and disconnect steering shaft from upper U joint (1) 10mm bolt.
6. Remove (4) 10mm bolts (2 per side) and nuts from both flanges at factory
connection point behind cats.
7. Disconnect O2 sensors (2 per side).
8. Remove (4) 10mm nuts (2 per side) from 2 bolt flanges at manifold and remove
cat pipes.
9. Remove 6mm nut and 8mm nut holding wires on starter then remove (3) 10 mm
bolts and the starter.
