WWW.STAINLESSWORKS.NET

800-878-3635

FAX: 440-543-9183


INSTALLATION INSTRUCTIONS FOR 2012+ JEEP SRT8
CATBACK


Thanks for purchasing Stainless Works Catback Exhaust for your 2012+ Jeep Grand
Cherokee SRT8. We have gone to great pains to make sure that our exhaust systems fit
and sound great. Please follow these steps to ensure that your installation goes as
planned.

1. Stainless Works recommends the use of Hi-Temp RTV sensor safe silicon

gasket maker as an option to or in conjunction with the use of factory gaskets.
The recommended Oxygen Sensor Safe RTV is either Valco All-in-One
Aluminum or Permatex Copper P/N 101BR available at NAPA, Autozone
and other retailers.

2. Disconnect the battery before starting work on the exhaust system for your

vehicle. Reconnect the battery when the job is completed.

3. Your exhaust system can be installed by a weekend warrior but the use of a

lift is recommended for ease of installation. If using a jack, the vehicle must
be placed on a level hard surface and jack stands are required for safety
reasons.

4. You will assemble the components together as specified below, but only snug

the clamps as you move along from front to back. When placing the X-pipe
into position, make certain that you push it fully forward and level it in with
the vehicle. After aligning all the components in the vehicle, you will tighten
all the clamps working from front to back of the vehicle.


5. Loosen (2) clamps holding tips on and remove tips to gain access to muffler

hangers.


6. Loosen clamp on left muffler inlet and remove muffler.

7. Loosen (4) 10mm spring loaded nuts from factory connection point after

converters.


8. Remove front hangers- (4) 8mm bolts from floor of vehicle and remove

exhaust.
