Skyjacker 9240 User Manual
Hardware bag breakdown: part # hb-7240

Ford
Dual Steering Stabilizer
Part # 7240 / 9240
I-7240 REV2 2-14
Pg 1
www.skyjacker.com
RequiReD Tool liST:
•
Safety Glasses
•
Metric / Standard Wrenches & Sockets
•
Measuring Tape
•
Torque Wrench
Before beginning the installation, thoroughly & completely read these instructions & the enclosed
driver’s WARNING NOTICE. Affix the WARNING decal in the passenger compartment in clear view
of all occupants. Please refer to the Parts List to insure that all parts & hardware are received prior
to the disassembly of the vehicle. If any parts are found to be missing, contact SKYJACKER®
Customer Service at 318-388-0816 to obtain the needed items. If you have any questions or
reservations about the installation of this product, contact SKYJACKER® Technical Assistance at
318-388-0816.
Component Box Breakdown:
Part #: 7240 / 9240
item #
Description
qty
item #
Description
qty
7800WS
WHITE STEERING DAMPER
2
BTIE
RED BOOT TIE
2
(included With 7240)
(included With 7240)
9800WS
SILVER STEERING DAMPER
2
BTIE-K
BLACK BOOT TIE
2
(included With 9240)
(included With 9240)
83540
MAIN BRACKET
1
HSS
HYDRO SHOCK DECAL
2
83541
TIE ROD BRACKET
1
(included With 7240)
B10RS
RED BOOT
2
SSD
SILVER STABILIZER DECAL
2
(included With 7240)
(included With 9240)
B10KS
BLACK BOOT
2
HB-7240
HARDWARE BAG: 7240 / 9240
1
(included With 9240)
I-7240
INST SHEET: 7240 / 9240
1
Hardware Bag Breakdown:
Part # HB-7240
item #
Description
qty
item #
Description
qty
38X614X4U
3/8 X 6 1/4 X 4 U-BOLT SQ
1
38SAEW
3/8 SAE WASHER
2
516X114X134U
5/16 X 1 1/4 X 1 3/4 U-BOLT RD 2
516SAEW
5/16 SAE WASHER
4
38CTN
3/8 COARSE THRD LOCK NUT 2
STEM BUSH-SST STEM BUSHING
8
516CTN
5/16 COARSE THR LOCK NUT 4
142120
STAB WASH PKG
4
