Ford Ranger / Bronco II /

Explorer

Dual Steering Stabilizer

Part # 7250 / 9250

I-7250 REV2 2-14

Pg 1

www.skyjacker.com

REquIRED Tool lIST:

Safety Glasses

Metric / Standard Wrenches & Sockets

Measuring Tape

Torque Wrench

Before beginning the installation, thoroughly & completely read these instructions & the enclosed

driver’s WARNING NOTICE. Affix the WARNING decal in the passenger compartment in clear view
of all occupants. Please refer to the Parts List to insure that all parts & hardware are received prior
to the disassembly of the vehicle. If any parts are found to be missing, contact SKYJACKER®

Customer Service at 318-388-0816 to obtain the needed items. If you have any questions or

reservations about the installation of this product, contact SKYJACKER® Technical Assistance at

318-388-0816.

Component Box Breakdown:

Part #: 7250 / 9250

Item #

Description

qty

Item #

Description

qty

7900WS

WHITE STEERING DAMPER

2

BTIE-K

BLACK BOOT TIE

2

(Included With 7250)

(Included With 9250)

9900WS

SILVER STEERING DAMPER

2

HSS

HYDRO SHOCK DECAL

2

(Included With 9250)

(Included With 7250)

83540

MAIN BRACKET

1

SSD

SILVER STABILIZER DECAL

2

B10RS

RED BOOT

2

(Included With 9250)

(Included With 7250)

HB-7250

HARDWARE BAG: 7250 / 9250

1

B10KS

BLACK BOOT

2

I-7250

INST SHEET: 7250 / 9250

1

(Included With 9250)

BTIE

RED BOOT TIE

2

(Included With 7250)

Hardware Bag Breakdown:

Part # HB-7250

Item #

Description

qty

Item #

Description

qty

83032

BACKING BRACKET

1

716X112FTB

7/16 X 1 1/2 FINE THRD BOLT 2

83098

TIE ROD BRACKET

1

716FTN

7/16 FINE THRD LOCK NUT 2

516X1X134U

5/16 X 1 X 1 3/4 U-BOLT RD

2

716SAEW

7/16 SAE WASHER

2

516CTN

5/16 COARSE THR LOCK NUT 4

STEM BUSH-SST STEM BUSHING

8

516SAEW

5/16 SAE WASHER

4

142120

STAB WASH PKG

4

716X4FTB

7/16 X 4 FINE THREAD BOLT 2
