Hardware bag breakdown: part # hb-7270

98-02 Dodge 2500/3500 4WD
Dual Steering Stabilizer
w/ 3 3/4" Front Axle Tube
Part # 7270 / 9270
I-7270 REV2 2-14
Pg 1
www.skyjacker.com
RequiReD Tool liST:
•
Safety Glasses
•
Metric / Standard Wrenches & Sockets
•
Measuring Tape
•
Torque Wrench
Before beginning the installation, thoroughly & completely read these instructions & the enclosed
driver’s WARNING NOTICE. Affix the WARNING decal in the passenger compartment in clear view
of all occupants. Please refer to the Parts List to insure that all parts & hardware are received prior
to the disassembly of the vehicle. If any parts are found to be missing, contact SKYJACKER®
Customer Service at 318-388-0816 to obtain the needed items. If you have any questions or
reservations about the installation of this product, contact SKYJACKER® Technical Assistance at
318-388-0816.
Component Box Breakdown:
Part #: 7270 / 9270
item #
Description
qty
item #
Description
qty
7000WS
WHITE STEERING DAMPER
2
BTIE-K
BLACK BOOT TIE
2
(included With 7270)
(included With 9270)
9000WS
SILVER STEERING DAMPER
2
HSS
HYDRO SHOCK DECAL
2
(included With 9270)
(included With 7270)
7254-B
MAIN BRACKET
1
SSD
SILVER STABILIZER DECAL
2
B10RS
RED BOOT
2
(included With 9270)
(included With 7270)
HB-7270
HARDWARE BAG: 7270 / 9270
1
B10KS
BLACK BOOT
2
I-7270
INST SHEET: 7270 / 9270
1
(included With 9270)
BTIE
RED BOOT TIE
2
(included With 7270)
Hardware Bag Breakdown:
Part # HB-7270
item #
Description
qty
item #
Description
qty
7218-DB
TIE ROD BRACKET / DRIVER
1
516CTN
5/16 COARSE THR LOCK NUT 8
7254-PB
TIE ROD BRACKET / PASS
1
38SAEW
3/8 SAE WASHER
4
38X334X412U 3/8 X 3 3/4 X 4 1/2 U-BOLT RD
2
516SAEW
5/16 SAE WASHER
8
516X114X134U 5/16 X 1 1/4 X 1 3/4 U-BOLT RD
2
140629
EB6 STUD BAG - P932/140629 4
516X134X258U 5/16 X 1 3/4 X 2 5/8 U-BOLT RD
2
HOURGLASS 5/8 HOURGLASS 5/8 BUSHING
4
38CTN
3/8 COARSE THREAD LOCK NUT 4
