Hardware bag breakdown: part # hb-7298

2001 - 2010 Chevy / GM
2500 HD / 3500 4WD
Dual Steering Stabilizer
Part # 7298 / 9298
I-7298 REV2 2-14
Pg 1
www.skyjacker.com
RequiReD Tool liST:
•
Safety Glasses
•
Metric / Standard Wrenches & Sockets
•
Measuring Tape
•
Torque Wrench
Before beginning the installation, thoroughly & completely read these instructions & the enclosed
driver’s WARNING NOTICE. Affix the WARNING decal in the passenger compartment in clear view
of all occupants. Please refer to the Parts List to insure that all parts & hardware are received prior
to the disassembly of the vehicle. If any parts are found to be missing, contact SKYJACKER®
Customer Service at 318-388-0816 to obtain the needed items. If you have any questions or
reservations about the installation of this product, contact SKYJACKER® Technical Assistance at
318-388-0816.
Component Box Breakdown:
Part #: 7298 / 9298
item #
Description
qty
item #
Description
qty
7500WS
WHITE STEERING DAMPER
2
BTIE-K
BLACK BOOT TIE
2
(included With 7298)
(included With 9298)
9500WS
SILVER STEERING DAMPER
2
HSS
HYDRO SHOCK DECAL
2
(included With 9298)
(included With 7298)
B12RS
RED BOOT
2
SSD
SILVER STABILIZER DECAL
2
(included With 7298)
(included With 9298)
B12KS
BLACK BOOT
2
HB-7298
HARDWARE BAG: 7298 / 9298
1
(included With 9298)
I-7298
INST SHEET: 7298 / 9298
1
BTIE
RED BOOT TIE
2
(included With 7298)
Hardware Bag Breakdown:
Part # HB-7298
item #
Description
qty
item #
Description
qty
7298-MB
MAIN STAB BRACKET
1
STEM BUSH-SST STEM BUSHING
4
7298-DT2
DRIV / TAB BRACKET
1
516X114X134U
5/16 X 1 1/4 X 1 3/4 U-BOLT RD 2
7298-PT2
PASS / TAB BRACKET
1
516CTN
5/16 COARSE THR LOCK NUT 4
140629
EB6 STUD BAG
2
516SAEW
5/16 SAE WASHER
4
142120
STAB WASH PKG
2
58USSW
5/8 USS WASHER
2
HOURGLASS 5/8 HOURGLASS 5/8 BUSHING
2
