Skyjacker 9098 - Manual

2001 - 2010 GM 2500 HD 4WD
2002- 2010 GM Hummer H2
Heavy Duty OEM
Steering Stabilizer
Installation Instructions
I-7098 REV2 12-13
www.skyjacker.com
Pg 1
Before beginning the installation, thoroughly & completely read these instructions. Please refer to
the Parts List to insure that all parts & hardware are received prior to the disassembly of the vehicle.
If any parts are found to be missing, contact SKYJACKER® Customer Service at 318-388-0816 to
obtain the needed items. If you have any questions or reservations about installing this product,
contact SKYJACKER® Technical Assistance at 318-388-0816.
REquIRED TOOl lIST:
• Safety Glasses
• Metric / Standard Wrenches & Sockets
• Torque Wrench
Hardware Bag Breakdown:
Part # HB-7098
Item # Description qty Item # Description qty
HOURGLASS 5/8 HOURGLASS 5/8 BUSHING 1 P837 STAB TAPERED STUD 1
HG58125 HOURGLASS 5/8" X 1.25" 1 403712 ES22 SLEEVE / 1.25" LONG 1
Component Box Breakdown:
Part #: 7098 / 9098
Item # Description qty Item # Description qty
7202WS WHITE STEERING DAMPER 1 BTIE-K BLACK BOOT TIE 1
(Included With 7098) (Included With 9098)
9202WS SILVER STEERING DAMPER 1 HSS HYDRO SHOCK DECAL 1
(Included With 9098) (Included With 7098)
B12RS RED BOOT 1 SSD SILVER STABILIZER DECAL 1
(Included With 7098) (Included With 9098)
B12KS BLACK BOOT 1 HB-7098 HARDWARE BAG: 7098 / 9098 1
(Included With 9098) I-7098 INST SHEET: 7098 / 9098 1
BTIE RED BOOT TIE 1
(Included With 7098)
