Skyjacker 9109 - Manual

1987 - 1996
Jeep Wrangler YJ
Single Steering Stabilizer
I-7109 REV2 1-14 Pg 1
www.skyjacker.com
RequiRed Tool liST:
• Safety Glasses
• Metric / Standard Wrenches & Sockets
• Tape Measure
• Torque Wrench
Before beginning the installation, thoroughly & completely read these instructions & the enclosed
driver’s WARNING NOTICE. Affix the WARNING decal in the passenger compartment in clear view
of all occupants. Please refer to the Parts List to insure that all parts & hardware are received prior
to the disassembly of the vehicle. If any parts are found to be missing, contact SKYJACKER®
Customer Service at 318-388-0816 to obtain the needed items. If you have any questions or
reservations about the installation of this product, contact SKYJACKER® Technical Assistance at
318-388-0816.
Component Box Breakdown:
Part #: 7109 / 9109
item # description qty item # description qty
7900WS WHITE STEERING DAMPER 1 BTIE-K BLACK BOOT TIE 1
(included With 7109) (included With 9109)
9900WS SILVER STEERING DAMPER 1 HSS HYDRO SHOCK DECAL 1
(included With 9109) (included With 7109)
B10RS RED BOOT 1 SSD SILVER STABILIZER DECAL 1
(included With 7109) (included With 9109)
B10KS BLACK BOOT 1 HB-7109 HARDWARE BAG: 7109 / 9109 1
(included With 9109) I-7109 INST SHEET: 7109 / 9109 1
BTIE RED BOOT TIE 1
(included With 7109)
Hardware Bag Breakdown:
Part # HB-7109
item # description qty item # description qty
83031 MAIN BRACKET 1 38SAEW 3/8 SAE WASHER 2
83161 TIE ROD BRACKET 1 516CTN 5/16 COARSE LOCK NUT 4
38X312FTB 3/8 X 3 1/2 FINE THREAD BOLT 2 516SAEW 5/16 SAE WASHER 4
516X1X134U 5/16 X 1 X 1 3/4 U-BOLT 2 STEM BUSH-SST STEM BUSHING 4
38FTN 3/8 FINE LOCK NUT 2 142120 STAB WASH PKG 2
