Hardware bag breakdown: part # hb-7119

Pg 1
I-7119 REV2 1-14
1997 - 2006 Jeep Wrangler TJ
Single Stabilizer
Installation Instructions
www.skyjacker.com
RequIRed Tool lIST:
•
Safety Glasses
•
Metric / Standard Wrenches & Sockets
•
Tape Measure
•
Torque Wrench
Before beginning the installation, thoroughly & completely read these instructions & the enclosed
driver’s WARNING NOTICE. Affix the WARNING decal in the passenger compartment in clear view
of all occupants. Please refer to the Parts List to insure that all parts & hardware are received prior
to the disassembly of the vehicle. If any parts are found to be missing, contact SKYJACKER
®
Customer Service at 318-388-0816 to obtain the needed items. If you have any questions or
reservations about the installation of this product, contact SKYJACKER
®
Technical Assistance at
318-388-0816.
Component Box Breakdown:
Part #: 7119 / 9119
Item #
description
qty
Item #
description
qty
7900WS
WHITE STEERING DAMPER
1
BTIE-K
BLACK BOOT TIE
1
(Included With 7119)
(Included With 9119)
9900WS
SILVER STEERING DAMPER
1
HSS
HYDRO SHOCK DECAL
1
(Included With 9119)
(Included With 7119)
B10RS
RED BOOT
1
SSD
SILVER STABILIZER DECAL
1
(Included With 7119)
(Included With 9119)
B10KS
BLACK BOOT
1
HB-7119
HARDWARE BAG: 7119 / 9119
1
(Included With 9119)
I-7119
INST SHEET: 7119 / 9119
1
BTIE
RED BOOT TIE
1
(Included With 7119)
Hardware Bag Breakdown:
Part # HB-7119
Item #
description
qty
Item #
description
qty
83161
TIE ROD BRACKET
2
516SAEW
5/16 SAE WASHER
8
516X1X134U
5/16 X 1 X 1 3/4 U-BOLT
2
142120
STAB WASH PKG
2
516X114X134U
5/16 X 1 1/4 X 1 3/4 U-BOLT
2
STEM BUSH-SST STEM BUSHING
4
516CTN
5/16-18 COARSE N/I LOCK NUT
8
