Skyjacker 9150 - Manual

Ford Ranger / BroncoII /
Explorer
Single Steering Stabilizer
Part # 7150 / 9150
I-7150 REV2 2-14 Pg 1
www.skyjacker.com
REquIREd Tool lIST:
• Safety Glasses
• Metric / Standard Wrenches & Sockets
• Measuring Tape
• Torque Wrench
Before beginning the installation, thoroughly & completely read these instructions & the enclosed
driver’s WARNING NOTICE. Affix the WARNING decal in the passenger compartment in clear view
of all occupants. Please refer to the Parts List to insure that all parts & hardware are received prior
to the disassembly of the vehicle. If any parts are found to be missing, contact SKYJACKER®
Customer Service at 318-388-0816 to obtain the needed items. If you have any questions or
reservations about the installation of this product, contact SKYJACKER® Technical Assistance at
318-388-0816.
Component Box Breakdown:
Part #: 7150 / 9150
Item # description qty Item # description qty
7900WS WHITE STEERING DAMPER 1 BTIE RED BOOT TIE 1
(Included With 7150) (Included With 7150)
9900WS SILVER STEERING DAMPER 1 BTIE-K BLACK BOOT TIE 1
(Included With 9150) (Included With 9150)
83031 MAIN BRACKET 1 HSS HYDRO SHOCK DECAL 1
83032 BACKING PLATE 1 (Included With 7150)
B10RS RED BOOT 1 SSD SILVER STABILIZER DECAL 1
(Included With 7150) (Included With 9150)
B10KS BLACK BOOT 1 HB-7150 HARDWARE BAG: 7150 / 9150 1
(Included With 9150) I-7150 INST SHEET: 7150 / 9150 1
Hardware Bag Breakdown:
Part # HB-7150
Item # description qty Item # description qty
83037 TIE ROD BRACKET 1 38FTN 3/8 FINE THREAD LOCK NUT 2
516X1X134U 5/16 X 1 X 1 3/4 U-BOLT RD 2 38SAEW 3/8 SAE WASHER 2
516CTN 5/16 COARSE THREAD LOCK NUT 4 STEM BUSH-SST STEM BUSHING 4
516SAEW 5/16 SAE WASHER 4 142120 STAB WASH PKG 2
38X112FTB 3/8 X 1 1/2 FINE THREAD BOLT 2
