Skyjacker 9186 User Manual
Hardware bag breakdown: part # hb-7186

1986-1995 Toyota IFS 4WD
Single Steering Stabilizer
Part # 7186 / 9186
I-7186 REV2 2-14
Pg 1
www.skyjacker.com
RequIReD Tool lIST:
•
Safety Glasses
•
Metric / Standard Wrenches & Sockets
•
Measuring Tape
•
Torque Wrench
Before beginning the installation, thoroughly & completely read these instructions & the enclosed
driver’s WARNING NOTICE. Affix the WARNING decal in the passenger compartment in clear view
of all occupants. Please refer to the Parts List to insure that all parts & hardware are received prior
to the disassembly of the vehicle. If any parts are found to be missing, contact SKYJACKER®
Customer Service at 318-388-0816 to obtain the needed items. If you have any questions or
reservations about the installation of this product, contact SKYJACKER® Technical Assistance at
318-388-0816.
Component Box Breakdown:
Part #: 7186 / 9186
Item #
Description
qty
Item #
Description
qty
7900WS
WHITE STEERING DAMPER
1
BTIE-K
BLACK BOOT TIE
1
(Included With 7186)
(Included With 9186)
9900WS
SILVER STEERING DAMPER
1
HSS
HYDRO SHOCK DECAL
1
(Included With 9186)
(Included With 7186)
5021
MAIN BRACKET
1
SSD
SILVER STABILIZER DECAL
1
B10RS
RED BOOT
1
(Included With 9186)
(Included With 7186)
HB-7186
HARDWARE BAG: 7186 / 9186
1
B10KS
BLACK BOOT
1
I-7186
INST SHEET: 7186 / 9186
1
(Included With 9186)
BTIE
RED BOOT TIE
1
(Included With 7186)
Hardware Bag Breakdown:
Part # HB-7186
Item #
Description
qty
Item #
Description
qty
83037
TIE ROD BRACKET
1
12X130MMBG5 12 X 130 MM METRIC BOLT 2
516X1X134U
5/16 X 1 X 1 3/4 U-BOLT RD
2
12MMN
12 MM METRIC LOCK NUT 2
516CTN
5/16 COARSE THREAD LOCK NUT 4
12SAEW
1/2 SAE WASHER
2
516SAEW
5/16 SAE WASHER
4
STEM BUSH-SST STEM BUSHING
4
DSS1234
SPACER 1/2 X 3/4
1
142120
STAB WASH PKG
2
