Skyjacker 9203 - Manual

2007- 2012 Jeep Wrangler JK
Dual Steering Stabilizer
Part # 7203 / 9203
I-7203 REV2 8-12 Pg 1
RequiReD Tool liST:
• Safety Glasses
• Metric / Standard Wrenches & Sockets
• Measuring Tape
• Torque Wrench
www.skyjacker.com
Before beginning the installation, thoroughly & completely read these instructions & the enclosed
driver’s WARNING NOTICE. Affix the WARNING decal in the passenger compartment in clear view
of all occupants. Please refer to the Parts List to insure that all parts & hardware are received prior
to the disassembly of the vehicle. If any parts are found to be missing, contact SKYJACKER®
Customer Service at 318-388-0816 to obtain the needed items. If you have any questions or
reservations about the installation of this product, contact SKYJACKER® Technical Assistance at
318-388-0816.
important Note:
• Steering stabilizer boots are not included with this dual stabilizer kit to maintain proper clearances.
Component Box Breakdown:
Part #: 7203 / 9203
item # Description qty item # Description qty
7500WS WHITE STEERING DAMPER 2 SSD SILVER STABILIZER DECAL 2
(included With 7203) (included With 9203)
9500WS SILVER STEERING DAMPER 2 HB-7203 HARDWARE BAG: 7203 / 9203 1
(included With 9203) I-7203 INST SHEET: 7203 / 9203 1
7203-MB MAIN BRACKET 1
HSS HYDRO SHOCK DECAL 2
(included With 7203)
Hardware Bag Breakdown:
Part # HB-7203
item # Description qty item # Description qty
7203-D DRIVERS BRACKET 1 STEM BUSH-SST STEM BUSHING 4
7203-FP FRONT PLATE BRACKET 1 516X112X2U 5/16 X 1 1/2 X 2 U-BOLT RD 4
7203-P PASSENGER BRACKET 1 516FSCTN 5/16 SERRATED CRSE NUT 8
140629 EB6 STUD BAG - P932/140629 2 38X234X3U 3/8 X 2 3/4 X 3 U-BOLT RD 2
142120 STAB WASH PKG - P889/145098 2 38FSCTN 3/8" SERRATED CRSE NUT 4
HOURGLASS 5/8 HOURGLASS 5/8 BUSHING 2
