Skyjacker 7239 User Manual
Kit box breakdown: part #: 7239
09-11 Dodge 2500 & 3500
4WD Dual Steering Stabilizer
Part # 7239
I-7239 REV1 3-11
Pg 1
Before beginning the installation, thoroughly & completely read these instructions & the enclosed
driver’s WARNING NOTICE. Affix the WARNING decal in the passenger compartment in clear view
of all occupants. Please refer to the Parts List to insure that all parts & hardware are received prior
to the disassembly of the vehicle. If any parts are found to be missing, contact SKYJACKER®
Customer Service at 318-388-0816 to obtain the needed items. If you have any questions or
reservations about the installation of this product, call SKYJACKER® Technical Assistance at 318-
388-0816.
RequiReD Tool liST:
•
Safety Glasses
•
Metric / Standard Wrenches & Sockets
•
Drill & Assorted Drill Bits
•
Torque Wrench
www.skyjacker.com
Kit Box Breakdown:
Part #: 7239
iTeM# DeSCRiPTioN qTY
Hardware Bag Breakdown:
HB-7239 HARDWARe BAG
iTeM# DeSCRiPTioN qTY
7000WS
WHITE STEERING DAMPER
2
7213-MB
03DGE,MAIN STRG STAB BRACKT
1
7213-DB
03DGE,DRIVER STRG STAB BRKT
1
7213-PB
03DGE,PASS STRG STAB BRACKT
1
B10RS
RED BOOT
2
BTIE
RED BOOT TIE
2
HB-7239
HDWR BAG: 7239 DUAL STAB
1
HSS
HYDRO SHOCK DECAL
2
I-7239
INST SHEET: 7239 DUAL STAB
1
12X112FTB
1/2 X 1 1/2 FINE THRD BOLT
1
12X3FTB
1/2 X 3 FINE THREAD BOLT
1
38X114FTB
3/8 X 1 1/4 FINE THD/GRD 8
4
38X1716X234U
3/8 X 1 7/16 X 2 3/4 U-BOLT
2
140629
EB6 STUD BAG - P932/140629
4
HOURGLASS 5/8
HOURGLASS 5/8 SHOCK BUSHING
4
12FTN
1/2-20 FINE N/I LOCK NUT
2
38CTN
3/8-16 COARSE N/I LOCK NUT
4
38FTN
3/8-24 FINE N/I LOCK NUT
4
12SAEW
1/2 SAE WASHER
4
