Skyjacker 9214 User Manual
Hardware bag breakdown: part # hb-7214

2014 Ram 2500 4WD
2013 - 2014 Ram 3500 4WD
Dual Steering Stabilizer
Part # 7214 / 9214
I-7214 3-14
Pg 1
www.skyjacker.com
RequiReD Tool liST:
•
Safety Glasses
•
Metric / Standard Wrenches & Sockets
•
Measuring Tape
•
Torque Wrench
Before beginning the installation, thoroughly & completely read these instructions & the enclosed
driver’s WARNING NOTICE. Affix the WARNING decal in the passenger compartment in clear view
of all occupants. Please refer to the Parts List to insure that all parts & hardware are received prior
to the disassembly of the vehicle. If any parts are found to be missing, contact SKYJACKER®
Customer Service at 318-388-0816 to obtain the needed items. If you have any questions or
reservations about the installation of this product, contact SKYJACKER® Technical Assistance at
318-388-0816.
Component Box Breakdown:
Part #: 7214 / 9214
item #
Description
qty
item #
Description
qty
7000WS
WHITE STEERING DAMPER
2
BTIE-K
BLACK BOOT TIE
2
(included With 7214)
(included With 9214)
9000WS
SILVER STEERING DAMPER
2
HSS
HYDRO SHOCK DECAL
2
(included With 9214)
(included With 7214)
7214-MB
MAIN BRACKET
1
SSD
SILVER STABILIZER DECAL
2
B10RS
RED BOOT
2
(included With 9214)
(included With 7214)
HB-7214
HARDWARE BAG: 7214 / 9214
1
B10KS
BLACK BOOT
2
I-7214
INST SHEET: 7214 / 9214
1
(included With 9214)
BTIE
RED BOOT TIE
2
(included With 7214)
Hardware Bag Breakdown:
Part # HB-7214
item #
Description
qty
item #
Description
qty
7214-6
FRONT PLATE BRACKET
1
38FTN
3/8 FINE THREAD LOCK NUT 2
7218-DB
TIE ROD BRACKET / PASS
1
516X112X214U 5/16 X 1 1/2 X 2 1/4 U-BOLT
2
7254-PB
TIE ROD BRACKET / DRIVER
1
516X134X258U
5/16 X 1 3/4 X 2 5/8 U-BOLT 2
CS0438
CRUSH SLEEVE. .438" LONG
2
516SAEW
5/16 SAE WASHER
8
10MMX30MMB 10MM X 30MM METRIC BOLT
2
516CTN
5/16 COARSE THR LOCK NUT 8
38X4X558U
3/8 X 4 X 5 5/8 U-BOLT
1
140629
EB6 STUD BAG - P932/140629 4
38SAEW
3/8 SAE WASHER
4
HOURGLASS 5/8 HOURGLASS 5/8 BUSHING
4
