‎Chapter 5 Configuring the PM135 Configuring Communications
74 PM135 Powermeter Series
GSM/GPRS modem in Chapter 2 on how to connect a modem to your
meter.
Using the Front Display
Select GPRS interface from the COM2 Setup menu. This menu entry
appears only if the optional GPRS module is plugged into the
meter. It allows you to set up the meter network address and the default
gateway.
See Viewing and Changing Setup Options in Chapter 3 for information on
configuring parameters via the front display
Device Setup
Reset
Real Time Clock
Display Setup
Basic Setup
Device Options
COM1 Setup
COM2 Setup
COM2 Setup
Protocol
Interface
Device Address
Modbus RTU
GPRS
1
Using PAS
To set up GPRS communications:
1. Select Communications Setup
from the Meter Setup menu, and
then click on the GPRS Setup tab.
Figure ‎5-3: Communication Setup Dialog Box – GPRS Setup Tab
