1
Chapter 1. Knowing Your Device
18 End key End a call or close Phone application.
19
5-way navigation
key Press the multi directional control up, down, left, or right to move
through menus; carry out the selection by pressing the center button.
0 Numeric keypad Enter numbers or letters by the numeric keypad.
1 Connect pins
Connect the connect pins of the device and the cradle (if any) for
recharging the battery.
Microphone
Speak into the microphone when talking on the phone or recording a
voice note.
Eyelet for wrist strap
(1)
Fix a wrist strap here.
Scan key (right) Press the key to scan and decode bar code/ D code.
Eyelet for wrist strap
(2)
Fix a wrist strap here.
Mini-SD card slot Insert a mini-SD card to expand device memory.
Mini USB connector Mini USB connector for PC sync and battery charging.
8 Earphone Jack Connect a . mm Earphone.
9 Speaker Listen to audio media or listen to a phone call hands-free.
0 Screw hole Fasten the provided strap set here with screws.
1 Cover latch Slide both of the cover latches to remove the battery cover.
Battery cover Remove to place battery and SIM card.
If you press the Reset button when your device is in use, the unsaved data and settings may be
lost.
