48
ELECTRICAL INFORMATION (cont.)
Table 43 – 548J*07 1--Stage Cooling 6 TONS
V---Ph---Hz
VOLTAGE
RANGE
COMP (ea) OFM (ea) IFM
RLA LRA WATTS FLA TYPE
Max
WATTS
Max
AMP Draw EFF at Full Load
FLA
MIN MAX
208---3---60 187 253 19.0 123 325 1.5
STD 1600 5.5 80% 5.2
MED 2770 7.9 81% 7.5
HIGH 2770 7.9 81% 7.5
230---3---60 187 253 19.0 123 325 1.5
STD 1600 5.5 80% 5.2
MED 2770 7.9 81% 7.5
HIGH 2770 7.9 81% 7.5
460---3---60 414 506 9.7 62 325 0.8
STD 1600 2.7 80% 2.6
MED 2770 3.6 81% 3.4
HIGH 2770 3.6 81% 3.4
575---3---60 518 633 7.4 50 325 0.6
STD 1600 2.5 80% 2.4
MED 2770 2.9 81% 2.8
HIGH 2770 2.9 81% 2.8
Table 44 – 548J*08 2--Stage Cooling 7.5 TONS
V---Ph---Hz
VOLTAGE
RANGE
COMP (Cir 1) COMP (Cir 2) OFM (ea) IFM
RLA LRA RLA LRA WATTS FLA TYPE
Max
WATTS
Max
AMP
Draw
EFF at
Full
Load
FLA
MIN MAX
208---3---60 187 253 13.1 83 13.1 83 325 1.5
STD 1310 5.5 80% 5.2
MED 2770 7.9 81% 7.5
HIGH 2770 7.9 81% 7.5
230---3---60 187 253 13.1 83 13.1 83 325 1.5
STD 1310 5.5 80% 5.2
MED 2770 7.9 81% 7.5
HIGH 2770 7.9 81% 7.5
460---3---60 414 506 6.1 41 6.1 41 325 0.8
STD 1310 2.7 80% 2.6
MED 2770 3.6 81% 3.4
HIGH 2770 3.6 81% 3.4
575---3---60 518 633 4.4 33 4.4 33 325 0.6
STD 1310 2.5 80% 2.4
MED 2770 2.9 81% 2.8
HIGH 2770 2.9 81% 2.8
Table 45 – 548J*09 2--Stage Cooling 8.5 TONS
V---Ph---Hz
VOLTAGE
RANGE
COMP (Cir 1) COMP (Cir 2) OFM (ea) IFM
RLA LRA RLA LRA WATTS FLA TYPE
Max
WATTS
Max
AMP
Draw
EFF at
Full
Load
FLA
MIN MAX
208---3---60 187 253 16.0 91 13.7 83 325 1.5
STD 1310 5.5 80% 5.2
MED 2770 7.9 80% 7.5
HIGH 2770 7.9 80% 7.5
230---3---60 187 253 16.0 91 13.7 83 325 1.5
STD 1310 5.5 80% 5.2
MED 2770 7.9 80% 7.5
HIGH 2770 7.9 80% 7.5
460---3---60 414 506 7.0 46 6.2 41 325 0.8
STD 1310 2.7 80% 2.6
MED 2770 3.6 80% 3.4
HIGH 2770 3.6 80% 3.4
575---3---60 518 633 5.6 37 4.8 37 325 0.6
STD 1310 2.5 80% 2.4
MED 2770 2.9 80% 2.8
HIGH 2770 2.9 81% 2.8
548J
