Bryant PACKAGED HEAT PUMP 548J User Manual
Page 33
33
Table 16 – HEATING CAPACITY
5 TONS
548J*06
RETURN
AIR
(°F DB)
CFM
(STANDARD AIR)
TEMPERATURE AIR ENTERING OUTDOOR COIL (°F DB AT 70% RH)
---10
0
10
17
30
40
47
50
60
55
1500
Capacity
22.7
28.3
34.2
38.6
47.4
54.3
60.0
62.6
70.3
Int. Cap.
21.0
26.1
31.4
35.2
41.5
54.3
60.0
62.6
70.3
2000
Capacity
22.8
28.5
34.4
38.9
47.9
55.3
60.9
63.1
70.9
Int. Cap.
21.1
26.2
31.6
35.4
42.0
55.3
60.9
63.1
70.9
2500
Capacity
24.2
30.0
35.9
40.4
49.6
56.9
62.3
64.4
72.0
Int. Cap.
22.4
27.6
33.0
36.8
43.5
56.9
62.3
64.4
72.0
70
1500
Capacity
19.9
25.8
31.9
36.3
45.2
51.7
57.6
60.0
67.9
Int. Cap.
18.4
23.7
29.3
33.1
39.6
51.7
57.6
60.0
67.9
2000
Capacity
20.1
26.1
32.3
36.7
45.8
52.9
58.4
61.0
68.8
Int. Cap.
18.6
24.0
29.6
33.5
40.1
52.9
58.4
61.0
68.8
2500
Capacity
21.5
27.6
33.8
38.3
47.5
54.7
60.4
62.7
70.2
Int. Cap.
19.9
25.4
31.1
35.0
41.6
54.7
60.4
62.7
70.2
80
1500
Capacity
17.6
23.7
30.0
34.6
43.5
50.2
55.7
58.2
66.1
Int. Cap.
16.3
21.9
27.6
31.5
38.1
50.2
55.7
58.2
66.1
2000
Capacity
17.8
24.1
30.5
35.1
44.3
51.2
56.6
59.4
67.2
Int. Cap.
16.5
22.2
28.0
32.0
38.8
51.2
56.6
59.4
67.2
2500
Capacity
19.3
25.6
32.1
36.8
46.0
53.1
58.8
61.1
68.8
Int. Cap.
17.8
23.6
29.4
33.5
40.3
53.1
58.8
61.1
68.8
Table 17 – HEATING CAPACITY
6 TONS
548J*07
RETURN
AIR
(°F DB)
CFM
(STANDARD AIR)
TEMPERATURE AIR ENTERING OUTDOOR COIL (°F DB AT 70% RH)
---10
0
10
17
30
40
47
50
60
55
1800
Capacity
22.4
29.8
37.1
42.5
53.5
62.4
68.6
71.2
80.3
Int. Cap.
20.7
27.4
34.1
38.8
46.9
62.4
68.6
71.2
80.3
2400
Capacity
24.6
32.1
39.6
45.1
56.4
65.6
71.5
74.2
83.8
Int. Cap.
22.7
29.5
36.3
41.1
49.4
65.6
71.5
74.2
83.8
3000
Capacity
27.4
35.0
42.5
48.2
59.5
68.6
74.5
77.2
86.8
Int. Cap.
25.3
32.2
39.0
43.9
52.1
68.6
74.5
77.2
86.8
70
1800
Capacity
17.7
25.5
33.2
38.6
49.5
58.5
65.0
67.7
76.5
Int. Cap.
16.4
23.5
30.5
35.2
43.4
58.5
65.0
67.7
76.5
2400
Capacity
19.9
27.9
35.8
41.4
52.7
62.0
68.4
71.0
80.3
Int. Cap.
18.4
25.7
32.9
37.7
46.2
62.0
68.4
71.0
80.3
3000
Capacity
22.8
30.9
38.9
44.5
56.1
65.5
71.7
74.4
83.9
Int. Cap.
21.1
28.4
35.7
40.6
49.2
65.5
71.7
74.4
83.9
80
1800
Capacity
13.9
21.9
29.9
35.5
46.2
55.3
62.0
64.9
73.7
Int. Cap.
12.8
20.2
27.4
32.3
40.5
55.3
62.0
64.9
73.7
2400
Capacity
16.0
24.4
32.6
38.4
49.6
59.0
65.8
68.6
77.5
Int. Cap.
14.8
22.5
29.9
35.0
43.5
59.0
65.8
68.6
77.5
3000
Capacity
18.8
27.4
35.8
41.6
53.1
62.7
69.4
72.1
81.4
Int. Cap.
17.4
25.2
32.8
37.9
46.6
62.7
69.4
72.1
81.4
LEGEND
Capacity --- Instantaneous Capacity (1000 Btuh) includes indoor fan motor heat @ARI static conditions
Int. Cap. --- Integrated Capacity is Instantaneous Capacity minus the effects of frost on the outdoor coil and the heat required to defrost
rh
--- Relative Humidity
db
--- Dry Bulb
548J
