Bryant PACKAGED HEAT PUMP 548J - Manual (Page 15)

15
Table 7 -- (cont.) ELECTRIC HEAT -- ELECTRICAL DATA 6 TONS
UN
IT
N
O
M
.V
---
P
H
---
H
Z
IFM
TYPE
ELECTRIC HEATER
PART NUMBER
CRHEATERXXXXXX
NOM
PWR
(kW)
APP
PWR
(kW)
SINGLE POINT KIT PART NUMBER
CRSINGLEXXXXXX
WITHOUT C.O. or UNPWRD C.O. WITH PWRD C.O.
WITHOUT P.E. WITH P.E. WITHOUT P.E. WITH P.E.
548J
*0
7
208/
230
---
3
---
60
STD
102A00 6.5 4.9/6.0 --- 037A00 037A00 037A00
104B00 10.5 7.9/9.6 038A00 038A00 038A00 038A00
105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00
104B00,104B00 21.0 15.8/19.3 039A00 039A00 039A00 039A00
104B00,105A00 26.5 19.9/24.3 039A00 039A00 039A00 039A00
MED
102A00 6.5 4.9/6.0 037A00 037A00 037A00 037A00
104B00 10.5 7.9/9.6 038A00 038A00 038A00 038A00
105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00
104B00,104B00 21.0 15.8/19.3 039A00 039A00 039A00 039A00
104B00,105A00 26.5 19.9/24.3 039A00 039A00 039A00 039A00
HIGH
102A00 6.5 4.9/6.0 037A00 037A00 037A00 037A00
104B00 10.5 7.9/9.6 038A00 038A00 038A00 038A00
105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00
104B00,104B00 21.0 15.8/19.3 039A00 039A00 039A00 039A00
104B00,105A00 26.5 19.9/24.3 039A00 039A00 039A00 039A00
46
0
---
3
---
60
STD
106A00 6.0 5.5 --- --- --- ---
108A00 11.5 10.6 --- --- --- ---
109A00 14.0 12.9 --- --- --- ---
108A00,108A00 23.0 21.1 037A00 037A00 037A00 037A00
108A00,109A00 25.5 23.4 037A00 037A00 037A00 037A00
MED
106A00 6.0 5.5 --- --- --- ---
108A00 11.5 10.6 --- --- --- ---
109A00 14.0 12.9 --- --- --- ---
108A00,108A00 23.0 21.1 037A00 037A00 037A00 037A00
108A00,109A00 25.5 23.4 037A00 037A00 037A00 037A00
HIGH
106A00 6.0 5.5 --- --- --- ---
108A00 11.5 10.6 --- --- --- ---
109A00 14.0 12.9 --- --- --- ---
108A00,108A00 23.0 21.1 037A00 037A00 037A00 037A00
108A00,109A00 25.5 23.4 037A00 037A00 037A00 037A00
--- No Single Point Kit required
LEGEND
APP PWR --- 208 / 230V / 460V / 575V
C.O. --- Convenient outlet
FLA --- Full load amps
IFM --- Indoor fan motor
NOM PWR --- 240V / 480V / 600V
P.E. --- Power exhaust
PWRD --- Powered convenient outlet
UNPWRD --- Unpowered convenient outlet
548J
