Bryant PACKAGED HEAT PUMP 548J - Manual (Page 43)

43
FAN PERFORMANCE (cont.)
Table 35 – 548J*08 7.5 TON HORIZONTAL SUPPLY
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (IN. WG)
0.2 0.4 0.6 0.8 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2250 --- --- 509 0.40 587 0.52 659 0.66 725 0.80
2438 --- --- 525 0.46 600 0.59 669 0.73 733 0.88
2625 465 0.40 543 0.53 614 0.67 680 0.82 743 0.97
2813 487 0.47 561 0.61 629 0.76 693 0.91 753 1.08
3000 510 0.55 580 0.70 646 0.86 707 1.02 765 1.19
3188 534 0.65 600 0.80 663 0.96 722 1.13 779 1.31
3375 557 0.75 621 0.91 681 1.08 738 1.26 793 1.44
3563 582 0.86 642 1.03 700 1.21 755 1.39 808 1.58
3750 606 0.99 664 1.17 720 1.35 773 1.54 824 1.74
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (IN. WG)
1.2 1.4 1.6 1.8 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2250 788 0.94 847 1.09 903 1.25 957 1.41 1009 1.58
2438 794 1.03 852 1.19 907 1.36 959 1.52 1010 1.70
2625 802 1.13 858 1.30 911 1.47 963 1.64 1012 1.82
2813 811 1.24 865 1.41 917 1.59 967 1.77 1016 1.96
3000 821 1.36 874 1.54 925 1.72 974 1.91 1021 2.11
3188 832 1.49 884 1.68 933 1.87 981 2.06 1028 2.26
3375 845 1.63 895 1.82 943 2.02 990 2.22 1035 2.43
3563 858 1.78 907 1.98 954 2.19 1000 2.40 1044 2.61
3750 873 1.94 920 2.15 966 2.36 1011 2.58 1054 2.80
Std static motor and drive (belt drive)
Med static motor and drive (belt drive)
High static motor and drive (belt drive)
Table 36 – 548J*08 7.5 TON VERTICAL SUPPLY
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (IN. WG)
0.2 0.4 0.6 0.8 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2250 --- --- 528 0.43 597 0.54 658 0.66 713 0.78
2438 470 0.37 548 0.50 615 0.62 675 0.75 729 0.88
2625 494 0.45 569 0.58 634 0.71 692 0.85 745 0.99
2813 518 0.53 590 0.67 653 0.82 710 0.96 763 1.11
3000 543 0.62 612 0.77 673 0.93 729 1.08 780 1.24
3188 568 0.72 635 0.89 694 1.05 749 1.21 799 1.38
3375 593 0.84 658 1.01 716 1.19 769 1.36 818 1.53
3563 619 0.97 681 1.15 737 1.33 789 1.52 837 1.70
3750 645 1.11 705 1.30 760 1.49 810 1.68 857 1.88
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (IN. WG)
1.2 1.4 1.6 1.8 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2250 764 0.89 812 1.02 856 1.14 899 1.26 939 1.39
2438 779 1.00 826 1.13 870 1.26 912 1.40 952 1.53
2625 795 1.12 841 1.26 885 1.40 926 1.54 966 1.68
2813 811 1.25 857 1.40 900 1.55 941 1.69 980 1.84
3000 828 1.39 873 1.55 916 1.70 956 1.86 995 2.02
3188 846 1.54 890 1.71 932 1.87 972 2.04 1010 2.21
3375 864 1.70 907 1.88 949 2.05 988 2.23 1026 2.40
3563 882 1.88 925 2.06 966 2.25 1005 2.43 1042 2.62
3750 902 2.07 944 2.26 984 2.45 1022 2.65 1059 2.84
Std static motor and drive (belt drive)
Med static motor and drive (belt drive)
High static motor and drive (belt drive)
548J
