New Era Pump Systems Inc.
www.SyringePump.com
Model NE-9000
Publication #1200-04 43
12.4.1 Program Function Commands
The following commands are relevant to the currently select Program Phase. Note: During a Pumping
Program’s operation, the currently selected Phase can change automatically.
PHASE NUMBER
PHN [ ]
Set/query currently selected Program Phase:
Set:
Currently selected Phase is set to . Previous Phase is stored in non-volatile memory
and the requested Phase is recalled from the non-volatile memory. Set is only valid if the
Pumping Program is not operating.
Query response:
Currently selected Phase.
PUMPING PROGRAM FUNCTION
FUN [ ]
Set/query the Pumping Program Phase’s function.
This command is relevant to the currently selected Phase. Set is only valid if the Pumping
Program is not operating
For a more detailed description of Program commands, see sec. 11.3, Program Function
Descriptions.
=>
Rate Data Functions
When a Phase’s function is set to a “Rate Data Function”, use the ‘RAT’, ‘VOL’, and
‘DIR’ commands to setup the pumping parameters.
RAT Pumping rate. ‘RATE’
INC Increment rate. ‘INCR’
DEC Decrement rate. ‘DECR’
Non-Rate Data Functions
STP Stop pump. ‘STOP’
JMP Jump to Program Phase. ‘JP:nn’
LOP Loop to previous loop start ‘nn’ times. ‘LP:nn’
PRI Program Selection Input. 'Pr:In'
PRL Program Selection Label definition. 'Pr:nn'
LPS Loop starting Phase. ‘LP:ST’
LPE Loop end Phase. ‘LP:EN’
PAS Pauses pumping for ‘nn’ seconds. ‘PS:nn’
PAS Pauses pumping for 'n.n' seconds. 'PS:n.n'
IF If Program input TTL pin low, jump to Phase. ‘IF:nn’
EVN Set event trigger trap. ‘EV:nn’
EVS Set event square wave trigger trap. 'ES:nn'
EVR Event trigger reset. ‘EV:RS’
BEP Sound short beep. ‘BEEP’
OUT Set programmable output pin. ‘OUT.n’
PUMPING RATE
RAT [ [ ] ]
Set/query pumping rate.
=> OM = Oz/min
MM = mL/min
