Model NE-9000
Publication #1200-04 41
12.2.4 RS-232 Protocol: Basic and Safe Mode Common Syntax
=> { | }
=> [ To pump
=> From pump
=> { | } Operational state of pump
=>
I Dispensing
W Withdrawing
S Pumping Program Stopped
P Pumping Program Paused
T Timed Pause Phase
U Operational trigger wait (user wait)
X Purging
=> A ? Alarm
=>
R Pump was reset (power was interrupted)
S Pump motor stalled
T Safe mode communications time out
E Pumping Program error
O Pumping Program Phase is out of range
Pump network address, 0 to 99
* System command
=> Response to command
=> (0x0D) Carriage return
=> (0x02) Start of packet transmission indicator
=> (0x03) End of packet transmission indicator
=> 16 bit CCITT CRC of (high byte,
low byte)
=> Number of bytes remaining in packet, including this
byte
12.2.5 Network Command Burst
The Network Command Burst feature is only applicable when communicating to a network of pumps.
This special feature allows commands to be sent to a network of pumps simultaneously. For example,
changing the pumping rates simultaneously on a network of pumps.
Note: Since this special feature violates the general communications protocol of one command-one
response, all of the pumps will be responding simultaneously, and therefore the communications response
to a Network Command Burst will be gibberish and should be ignored.
Command Format
Command Burst => *
Network Command Burst => < Command Burst > [Network Command Burst]
Where indicates the address of the pump that is to execute . Maximum address is 9.
n => {0 ... 9}
Example: Simultaneously change the pumping rates of 3 pumps on a pump network as follows:
Pump 0: 100 ml/min
Pump 1: 250 ml/min
Pump 2: 375 ml/min
