DCA150SSJU3 50 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/01/10) — PAGE 71
GENERATOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 C0110000112 ROTOR ASSY. ..............................1 ..... INCLUDES ITEMS W/#
1-1# FIELD ASSY. 1
1-2# 8131070013 FAN 1
1-3# 8131611014 COUPLING DISK 8
1-4# 8131015003 BALANCING PLATE .....................1 ..... PURCHASE ITEMS 1-1 THRU 1-14 AS A SET
1-5# 0012112035 HEX, HEAD BOLT 10
1-6# 0042612000 WASHER, LOCK 10
1-7# 8101026013 SET, PLATE, RECTIFIER .............1 ..... PURCHASE ITEMS 1-1 THRU 1-14 AS A SET
1-8# 0601821349 RECTIFIER 2
1-9# 0601822601 SURGE ABSORBER 1
1-10# 8001020004 INSULATOR WASHER 1
1-11# 8001020504 INSULATOR WASHER 1
1-12# 0010110020 HEX, HEAD BOLT 4
1-13# 0040010000 WASHER, LOCK 4
1-14# 0601000209 BALANCING WEIGHT KIT 1
1-15# 0076506312 BEARING 1
2 C0130000603 STATOR ASSY. .............................1 ..... REPLACES P/N C0134000904/M3960100324
3 0845041804 GROMMET 2
4 8131315202 END BRACKET 1
5 8101350013 FIELD ASSY., EXCITER 1
6 0012110060 HEX, HEAD BOLT 4
7 0042610000 WASHER, LOCK 4
8 0041210000 WASHER, FLAT 4
9 0010112035 HEX, HEAD BOLT 6
10 0040012000 WASHER, LOCK 6
11 0041212000 WASHER, FLAT 6
12 8131310104 COVER, BEARING 1
13 8131312204 GASKET, BEARING 1
14 8131331003 COVER, END BRACKET 1
15 0017106012 HEX, HEAD BOLT 10
16 8101333003 COVER, END BRACKET 1
17 0010106030 HEX, HEAD BOLT 2
18 0040006000 WASHER, LOCK 2
19 0041206000 WASHER, FLAT 2
20 M3163400303 COUPLING RING 1
21 0343204220 HEX, HEAD BOLT 8
22 0043604000 WASHER, LOCK 8
23 0070506306 BEARING 1
24 0012810030 HEX, HEAD BOLT 12
25 0012810030 HEX, HEAD BOLT 12
26 C0131300004 COVER, FAN 1
27 0600815000 NUT 1
28 0605000013 RUBBER SUSPENSION 2
29 0030016000 HEX, NUT 2
29A 0040016000 WASHER, LOCK 2
