DCA150SSJU3 50 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/01/10) — PAGE 17
MAJOR COMPONENTS
Figure 3. Major Components
Table 4. Generator Major Components
ITEM NO.
DESCRIPTION
1
Muffl er Assembly
2
Air Filter Assembly
3
Output Terminal Assembly
4
Output Receptacles Assembly
5
Generator Assembly
6
Engine Assembly
7
Battery Assembly
8
Fuel Tank Assembly
9
Circuit Breaker Assembly
10
Engine Control Panel Assembly
11
Generator Control Panel Assembly
